Supply Voltage:
24 → 240V ac/dc
Mounting Type:
Panel Mount
Mode of Operation:
Delay on Start, Interval, OFF Delay (Delay on Break), ON Delay (Delay ON Make), ON/OFF Delay (Delay on Make/Break), One Shot, Recycler (Off Start), Recycler (On Start), Symmetrical Flashing (Off Start), Symmetrical Flashing (On Start)
Time Range:
0.001 → 9.999 s, 0.01 → 99.99 s, 0.1 → 999.9 min, 0.1 → 999.9 h, 0.1 → 999.9 s, 1 min → 99 h 59 min, 1 s → 99 min 59 s, 1 → 9999 h, 1 → 9999 s, 1 → 9999min
Number of Contacts:
1
Number of Timer Functions:
Multi Function
Contact Configuration:
SPDT
Time Increment:
Hours, Minutes, Seconds
Maximum Current:
10A
Maximum Voltage:
240V ac/dc
Terminal Type:
11-Pin Connector
Switch Configuration:
SPDT
Power Supply:
External
Minimum Voltage:
24V ac/dc
Width:
48mm
Maximum Operating Temperature:
+60°C
Minimum Current:
0.3A
Length:
48mm
Depth:
68mm
Series:
Syr-Line
Minimum Operating Temperature:
-10°C
