tsr-05-2433sm TRACOPOWER Switching Regulator, Surface Mount, 3.3V dc Output Voltage, 4.75 → 32V dc Input Voltage, 500mA Output
tsr-05-2433sm TRACOPOWER Switching Regulator, Surface Mount, 3.3V dc Output Voltage, 4.75 → 32V dc Input Voltage, 500mA Output

TRACOPOWER Switching Regulator, Surface Mount, 3.3V dc Output Voltage, 4.75 → 32V dc Input Voltage, 500mA Output

TRACOPOWER Switching Regulator, Surface Mount, 3.3V dc Output Voltage, 4.75 → 32V dc Input Voltage, 500mA Output

Manufacturer:
TRACOPOWER
Manufacturer Part No:
TSR 0.5-2433SM
Enrgtech Part No:
ET13935261
Warranty:
Manufacturer
$ 9.11 $ 9.11
Checking for live stock
Output Voltage:
3.3V dc
Output Current:
500mA
Input Voltage:
4.75 → 32V dc
Mounting Type:
Surface Mount
Number of Outputs:
1
Package:
SIP
Efficiency:
81% @ 32 V dc, 91% @ Vin min
Ripple And Noise:
30mV Pk-Pk
Minimum Temperature:
-40°C
Maximum Temperature:
+90°C
Series:
TSR
Line Regulation:
0.4%
Application:
General Purpose
Protection Features:
Over Temperature Protection, Short Circuit Protection
Weight:
1.7g
Width:
9.6mm
Depth:
9.24 (With Pin)mm
Standards Met:
EN 55022 Certified, EN 61000-4-2 Certified, EN 61000-4-3 Certified, EN 61000-4-4 Certified, EN 61000-4-6 Certified, EN 61000-4-8 Certified, IPC J-STD-020D.1, RoHS Compliant
Length:
15.3mm
Maximum Monitored Voltage:
Maximum of 330kHz
Input Power Range:
1.5W
Special Features:
Adjustable Output Voltage, Excellent Line/Load Regulation, Low Standby Current, Remote ON/OFF Input
Load Regulation:
0.6%
Minimum Monitored Voltage:
DC-DC
MTBF:
>2000000h
Maximum Input Current:
5mA
pdf icon
0900766b816ed3ff.pdf(datasheets)
pdf icon
A700000008244108.pdf(datasheets)
pdf icon
A700000008244136.pdf(datasheets)
Product Reviews
