Maximum Load Current:
125 A
Mounting Type:
Panel Mount
Maximum Load Voltage:
530 V ac
Minimum Load Voltage:
48 V ac
Minimum Control Voltage:
4 V dc
Maximum Control Voltage:
32 V dc
Switching Type:
Zero Cross
Control Voltage Range:
4 → 32 V dc
Minimum Load Current:
150mA rms
Number of Poles:
1
Terminal Type:
Screw
Output Device:
SCR
Relay Type:
Solid State Relay
Maximum Turn On Time:
1/2 cycle
Load Voltage Range:
48 → 530V ac
Series:
HD
Dimensions:
44.5 x 57.3 x 26.4mm
Height:
26.4mm
Operating Temperature Range:
-40 → +80°C
Length:
44.5mm
Capacitance:
8pF
Minimum Operating Temperature:
-40°C
Off State Leakage Current:
1mArms
Depth:
57.3mm
Maximum Operating Temperature:
+80°C
Special Features:
AC or DC Control, Direct Bond Copper Substrate, Direct Power Lead Frame, Epoxy-Free Design, Improved SEMS Screw & Washer, Redesigned Housing with Anti-Rotation Barriers
Standards Met:
CE, CSA LR 81689, cULus Recognised E116949, cULus Recognised E116950, EN 60950-1, IEC, IEC 60068-2-27, IEC 60068-2-6, IEC 61000-4-2, IEC 61000-4-4, IEC 62314, UL, VDE Approved 10143 UG
