d4825k Sensata Crydom 1 Series Solid State Relay, 25 A Load, Panel Mount, 530 V rms Load, 32 V dc Control
d4825k Sensata Crydom 1 Series Solid State Relay, 25 A Load, Panel Mount, 530 V rms Load, 32 V dc Control

Sensata Crydom 1 Series Solid State Relay, 25 A Load, Panel Mount, 530 V rms Load, 32 V dc Control

Sensata / Crydom D4825K Sensata Crydom 1 Series Solid State Relay, 25 A Load, Panel Mount, 530 V rms Load, 32 V dc Control

Manufacturer:
Sensata / Crydom
Manufacturer Part No:
D4825K
Enrgtech Part No:
ET16684884
Warranty:
Manufacturer
$ 86.20 $ 86.20
Checking for live stock
Maximum Load Current:
25 A
Mounting Type:
Panel Mount
Maximum Load Voltage:
530 V rms
Minimum Load Voltage:
48Vrms
Minimum Control Voltage:
4 V dc
Maximum Control Voltage:
32 V dc
Switching Type:
Zero Cross
Control Voltage Range:
4 → 32 V dc
Minimum Load Current:
150mA rms
Number of Poles:
1
Terminal Type:
Screw
Output Device:
SCR
Relay Type:
Solid State Relay
Load Voltage Range:
48 → 530Vrms
Series:
1
Maximum Turn On Time:
1/2 cycle
Dimensions:
44.5 x 57.3 x 26.4mm
Maximum Operating Temperature:
+80°C
Off State Leakage Current:
1mArms
Length:
44.5mm
Operating Temperature Range:
-40 → +80°C
Height:
26.4mm
Capacitance:
8pF
Minimum Operating Temperature:
-40°C
Depth:
57.3mm
Standards Met:
CE, CSA LR 81689, cULus Recognised E116950, EN 60950, EN 60950-1, IEC 62314, UL, VDE Approved 10139 UG
Special Features:
AC or DC Control, Direct Bond Copper Substrate, Direct Power Lead Frame, Epoxy-Free Design, Improved SEMS Screw & Washer, Redesigned Housing with Anti-Rotation Barriers
pdf icon
0900766b815d8a69.pdf(datasheets)
pdf icon
0900766b8168d28c.pdf(datasheets)
pdf icon
A700000008258246.pdf(datasheets)
