so763090 Celduc SO7 Series Solid State Relay, 35 A Load, Panel Mount, 510 V ac Load, 32 V dc Control
so763090 Celduc SO7 Series Solid State Relay, 35 A Load, Panel Mount, 510 V ac Load, 32 V dc Control

Celduc SO7 Series Solid State Relay, 35 A Load, Panel Mount, 510 V ac Load, 32 V dc Control

Celduc SO7 Series Solid State Relay, 35 A Load, Panel Mount, 510 V ac Load, 32 V dc Control

Manufacturer:
Celduc
Manufacturer Part No:
SO763090
Enrgtech Part No:
ET13835539
Warranty:
Manufacturer
$ 76.03 $ 76.03
Checking for live stock
Maximum Load Current:
35 A
Mounting Type:
Panel Mount
Maximum Load Voltage:
510 V ac
Minimum Load Voltage:
25 V ac
Maximum Control Voltage:
32 V dc
Minimum Control Voltage:
3.5 V dc
Switching Type:
Random
Control Voltage Range:
3.5 → 32 V dc
Range:
SO7
Minimum Load Current:
5 mA
Number of Poles:
1
Terminal Type:
Screw
Output Device:
Thyristor
Relay Type:
AC
Maximum Turn On Time:
0.1ms
Series:
SO7
Load Voltage Range:
25 → 510V ac
Dimensions:
45 x 58.5 x 30mm
Minimum Operating Temperature:
-55°C
Maximum Operating Temperature:
+100°C
Depth:
58.5mm
Length:
45mm
Special Features:
Over-Voltage Protection, Green LED Visualization on The Input, IP20 Protection by Removable Flaps on Terminals with Optional Labels
Standards Met:
CE Certified, cULus Recognized
Off State Leakage Current:
5 mA
Height:
30mm
Operating Temperature Range:
-55 → +100°C
pdf icon
0900766b81728a77.pdf(datasheets)
