Thread Size:
M30
Sensor Technology:
Inductive
Body Style:
Threaded Barrel
Detection Range:
23 mm
Digital Switching Output Type:
PNP/NPN
Output Function:
NO/NC
Connection Type:
M12
Supply Voltage:
10 → 30 V dc
Length:
65mm
IP Rating:
IP65, IP66, IP67, IP68, IP69K
Mounting Type:
Non-Flush
Housing Material:
Bronze, PBT, PEI
Maximum DC Voltage:
30V
Minimum Operating Temperature:
-40°C
Short Circuit Overload Protection:
Yes
Reverse Polarity Protection:
Yes
Maximum Switching Frequency:
100Hz
Switching Current:
10 mA
Communication Protocol:
IO-LINK
Shielding:
Unshielded
Maximum Operating Temperature:
+85°C
Switching Frequency:
100 Hz
Standards Met:
CE, cULus, DIN EN 60947-5-2, EAC, EN 55011, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-6, IEC 61131-9
