Multimeter Type:
Handheld
Model Number p:
0.032mm²
Display Type:
Digital
Calibrated:
UKAS
Functions Measured:
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Resistance
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum Resistance Measurement:
50MΩ
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum Capacitance Measurement:
9.999F
True RMS:
No
AC Current Measurement Resolution:
0.01mA ac
DC Current Measurement Resolution:
0.01mA dc
DC Voltage Measurement Resolution:
0.1mV dc
AC Voltage Measurement Resolution:
1mV ac
Resistance Measurement Resolution:
100mΩ
Safety Category Level:
CAT III, CAT IV
Height:
43mm
Minimum Operating Temperature:
-10°C
Best DC Current Accuracy:
±2.5% + 2 Digits
Maximum Operating Temperature:
+50°C
Best Resistance Measurement Accuracy:
±2% + 1 Digit
Dimensions:
185 x 90 x 43mm
Weight:
420g
Safety Category Voltage:
600 V, 1000V
Best AC Voltage Accuracy:
±2% + 2 Digits
Best AC Current Accuracy:
±2.5% + 2 Digits
Length:
185mm
Best DC Voltage Accuracy:
±0.3% + 1 Digit
Width:
90mm
Best Capacitance Measurement Accuracy:
±10 %
