Multimeter Type:
Handheld
Display Type:
Digital
Model Number p:
28EX
Calibrated:
UKAS
Functions Measured:
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Diode, Duty Cycle, Frequency, Resistance, Temperature
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum Resistance Measurement:
50MΩ
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum AC Current Measurement:
10A ac
True RMS:
Yes
Absolute Maximum Temperature Measurement:
+1090°C
Absolute Maximum Capacitance Measurement:
9.999F
Maximum Frequency:
200kHz
DC Current Measurement Resolution:
0.01A dc
AC Current Measurement Resolution:
0.01A ac
DC Voltage Measurement Resolution:
1V dc
Resistance Measurement Resolution:
10kΩ
AC Voltage Measurement Resolution:
1V ac
Safety Category Level:
CAT IV
Capacitance Measurement Resolution:
1µF
Hazardous Area Certification:
ATEX
Temperature Measurement Resolution:
0.1°C
Best AC Current Accuracy:
±1% + 2 Digits
Length:
213.3mm
Best DC Voltage Accuracy:
±0.1% + 1 Digit
Safety Category Voltage:
600V
Battery Type:
AAA
Width:
100mm
Maximum Operating Temperature:
+50°C
Best Temperature Measurement Accuracy:
±1% + 10 Digits
Dimensions:
213.3 x 100 x 45.7mm
Best Capacitance Measurement Accuracy:
±1% + 2 Digits
Best AC Voltage Accuracy:
±2% + 20 Digits
Minimum Operating Temperature:
-15°C
Height:
45.7mm
Weight:
567.8g
Best DC Current Accuracy:
±0.2% + 4 Digits
Best Resistance Measurement Accuracy:
±1% + 3 Digits
