Multimeter Type:
Bench
Model Number p:
2100/230-240
Display Type:
Digital
Functions Measured:
AC Current, AC Voltage, DC Current, DC Voltage, Resistance, Temperature
Absolute Maximum DC Current Measurement:
3A dc
Absolute Maximum Resistance Measurement:
100MΩ
Absolute Maximum AC Current Measurement:
3A ac
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum AC Voltage Measurement:
750V ac
Absolute Maximum Temperature Measurement:
+630°C
True RMS:
No
Maximum Frequency:
300kHz
AC Current Measurement Resolution:
1µA ac
DC Current Measurement Resolution:
10nA dc
AC Voltage Measurement Resolution:
0.1µV ac
DC Voltage Measurement Resolution:
0.1µV dc
Resistance Measurement Resolution:
100mΩ
Temperature Measurement Resolution:
0.001°C
Weight:
4.1kg
Best DC Current Accuracy:
±0.0055% + 0.025
Best Resistance Measurement Accuracy:
±1% + 0.02
Dimensions:
112 x 256 x 375mm
Best AC Voltage Accuracy:
±4.35% + 0.5
Best AC Current Accuracy:
±1.25% + 0.07
Best DC Voltage Accuracy:
±0.0055% + 0.001
Best Temperature Measurement Accuracy:
±0.2 °C
Maximum Operating Temperature:
+40°C
Minimum Operating Temperature:
+5°C
