Multimeter Type:
Bench
Model Number p:
34450A
Display Type:
Digital
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature
Calibrated:
UKAS
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
100MΩ
Absolute Maximum AC Voltage Measurement:
750V ac
True RMS:
Yes
Absolute Maximum Temperature Measurement:
+150°C
Absolute Maximum Capacitance Measurement:
10mF
Maximum Frequency:
100kHz
Safety Category Level:
CAT I, CAT II
Best Temperature Measurement Accuracy:
±0.2 °C
Best AC Voltage Accuracy:
±0.2% + 0.1
Length:
261.1mm
Best AC Current Accuracy:
±0.5% + 0.1
Width:
303.2mm
Height:
103.8mm
Best Capacitance Measurement Accuracy:
1 + 0.5
Safety Category Voltage:
600 V, 1000V
Maximum Operating Temperature:
+55°C
Best DC Voltage Accuracy:
±0.015 %
Minimum Operating Temperature:
0°C
Best DC Current Accuracy:
±0.05% + 0.007
Weight:
3.8kg
Dimensions:
261.1 x 303.2 x 103.8mm
Best Resistance Measurement Accuracy:
±0.05% + 0.008
