Multimeter Type:
Handheld
Display Type:
Digital
Model Number p:
U1242B
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature
Calibrated:
RSCAL
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
100MΩ
Absolute Maximum Capacitance Measurement:
10mF
True RMS:
Yes
Absolute Maximum Temperature Measurement:
+1000°C
Maximum Frequency:
2kHz
DC Current Measurement Resolution:
0.1µA dc
AC Current Measurement Resolution:
0.1µA ac
Resistance Measurement Resolution:
100mΩ
AC Voltage Measurement Resolution:
0.1mV ac
DC Voltage Measurement Resolution:
0.1mV dc
Capacitance Measurement Resolution:
100pF
Temperature Measurement Resolution:
0.1°C
Safety Category Level:
CAT III, CAT IV
Best Capacitance Measurement Accuracy:
±2% + 4 Digits
Best AC Voltage Accuracy:
±1% + 5 Digits
Best AC Current Accuracy:
±1.5% + 5 Digits
Width:
92.2mm
Safety Category Voltage:
600 V, 1000V
Best Temperature Measurement Accuracy:
±1% + 1 °C
Dimensions:
58 x 92.2 x 193.8mm
Maximum Operating Temperature:
+55°C
Best DC Voltage Accuracy:
±0.15% + 5 Digits
Length:
58mm
Best DC Current Accuracy:
±0.6% + 5 Digits
Best Resistance Measurement Accuracy:
±1.5% + 3 Digits
Minimum Operating Temperature:
-10°C
Height:
193.8mm
Weight:
450g
Battery Type:
AAA x 4
