Loop Impedance Test Type:
High/Low Current
Automatic RCD Test:
Yes
Model Number p:
MFT-X1-BS
RCD Ramp Test:
Yes
Non-Tripping:
Yes
Insulation Test Voltage:
50 V dc, 100 V dc, 250 V dc, 500 V dc, 1000V dc
Maximum Voltage Measurement:
1000V dc
Test Type:
AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Resistance
Earth Resistance Measurement:
Yes
Downloadable Data:
Yes
Continuity Test Current:
10mA
RCD Test Type:
A, AC, B
IP Rating:
IP54
Power Source:
Battery
Length:
274mm
Minimum Continuity Resistance:
0.01Ω
Continuity Range:
0.01 → 999 k Ω
Width:
96mm
Dimensions:
274 x 96 x 143mm
Height:
143mm
Plug Type:
BS 1363
Maximum Continuity Resistance:
999kΩ
Weight:
1.6kg
Operating Temperature Range:
-10 → +55 °C
Safety Category:
CAT III 600 V/CAT IV 300 V
Display Type:
TFT
Maximum Operating Temperature:
+55°C
Battery Type:
Li-Ion
Minimum Operating Temperature:
-10°C
Voltage Measurement Range:
0.001 → 1000V dc
Safety Category Voltage:
300 V, 600 V
