Properties Measured:
Current, Thermocouples, Thermoresistance, Voltage
Display Type:
LED
Cutout Height:
43mm
Cutout Width:
90.5mm
Depth:
102mm
Number of Digits:
4
Digit Height:
20 mm
Minimum Temperature:
0°C
Maximum Temperature:
+50°C
Measurement Range:
+250 → +1820 (B Type) °C, 0 → 10 V, 0 → 20 mA, -100 → +600 °C, -200 → +1000 (E Type) °C, -200 → +1300 (N Type) °C, -200 → +1370 (K Type) °C, -200 → +400 (T Type) °C, -210 → +1200 (J Type) °C, -50 → +1768 (R Type) °C, -50 → +1768 (S Type) °C
Meter Type:
Digital
Minimum Measurement:
+250 (B Type) °C, -200 (E Type) °C, -200 (K Type) °C, -200 (N Type) °C, -200 (T Type) °C, -210 (J Type) °C, -50 (R Type) °C, -50 (S Type) °C, -100 °C, 0 mA, 0 V
Approvals:
CE
