Power Rating:
4 kW
Phase:
3
Supply Voltage:
400 V ac
Current Rating:
5.4 A, 6 A, 6.7 A, 7.6 A
Series:
Altivar
For Use With:
Asynchronous Motors, Synchronous Motors
Field Bus Communication Type:
Profibus
IP Rating:
IP21
Output Frequency:
0.1 → 500Hz
STO:
Yes
Drive Type:
Variable Frequency
Mounting Type:
Wall Mount
Filter Included:
Yes
Control Panel:
Yes
Better World Claim:
Saves energy
Better World Verification:
Green Premium
Better World Product:
Yes
Overall Width:
203mm
Special Features:
Embedded Power Measurement & Energy Dashboard, Energy Saving, Fluids Management Processing, Services Oriented Drive
Overall Depth:
350mm
Overall Length:
144mm
Function:
Motor Control
Standards Met:
ATEX, CE, CSA, cUL, EAC, EN 954-1, EN ISO 13849-1, EN ISO 13849-2, IEC 60204-1, IEC 6100, IEC 61158, IEC 61508, IEC 61784, IEC/EN 60721, TUV, UL 508C
