bd01 C & K 1 Way Through Hole DIP Switch SPST, Extended Actuator

C & K BD Series Vertical DIP Switches Vertical full profile DIP switches from C & K feature an open bottom construction to allow for solder washing without the need for a tape seal Features and Benefits

Traditional full profile DIP switch

Switch contact rating: 100 mA @ 5 V dc / 25 mA @ 25 V dc

Life: 10000 make and break cycles at full load

Applications

Address switch for industrial controls

Logic switching for computers and peripherals

Function controlling for numerous applications

For more information please check the datasheets.

C & K 1 Way Through Hole DIP Switch SPST, Extended Actuator

Name: C & K 1 Way Through Hole DIP Switch SPST, Extended Actuator
Brand: C & K
SKU: ET16909189
Availability: InStock

Manufacturer:

C & K

Manufacturer Part No:

BD01

Enrgtech Part No:

ET16909189

Warranty:

Manufacturer

$ 1.26

Checking for live stock

Number of Positions:

Mounting Type:

Through Hole

Contact Material:

Gold over Nickel Plated Phosphor Bronze

Contact Configuration:

SPST

Package Style:

DIP

Actuator Type:

Extended

Contact Current Rating:

25 mA@ 25 V dc

Mechanical Life:

10000Cycles

Maximum Operating Temperature:

+85°C

Minimum Operating Temperature:

-40°C

Operating Temperature Range:

-40 → +85°C

Datasheet-afdcaa0c(datasheets)

Enrgtech offers DIP and SIP switches for reliable PCB configuration, ensuring accurate settings in electronics, instruments, and custom circuit applications.
