Series:
PRO ECO
Type:
Switched Mode
Electrical Phase:
1
Number of Outputs:
1
AC or DC Input Voltage:
ac, dc
Input Voltage:
85 → 264 V ac / 80 → 370V dc
AC or DC Output Voltage:
dc
Output Voltage:
48V dc
Output Current:
10A
Width:
100mm
Height:
125mm
Depth:
120mm
Mounting Type:
DIN Rail Mount
Efficiency:
93%
Output Voltage Adjustment Range:
42 → 56V
Ripple And Noise:
<100mV
MTBF:
>500000h
Special Features:
Compact Size, Easy to Maintain, High Efficiency
Minimum Temperature:
-25°C
Maximum Temperature:
+70°C
Standards Met:
61000-4-4, 61000-4-5, 61000-4-6, CE Certified, cULus Listed, EAC, EN 50178/VDE 0160, EN 55022, EN 60204, EN 60950, EN 61000-3-2, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-8, IEC 1709, IEC 60068-2-27, IEC 60068-2-6, IEC 61558-2-16, VDE 0100-410/DIN57100-410, VDE 0106-101
