Model Number:
1736/EUS
Number of Input Channels:
4
Measurement Parameters:
Current, Current Harmonic, Frequency, TDD, THD Current, THD Voltage, Unbalance, Voltage, Voltage Harmonic
Interface Type:
Bluetooth, USB, Wi-Fi
Data Logger Type:
Three Phase Power
Maximum Voltage Measurement:
1000V
Communication Protocol:
USB
Power Source:
Battery
IP Rating:
IP50
Minimum Operating Temperature:
-10°C
Maximum Operating Temperature:
+50°C
Maximum Current Measurement:
1500A
Display Type:
LCD
Battery Type:
Rechargeable Lithium-Ion
Best Current Measurement Accuracy:
± (1 % + 0.02 %)
Includes:
500A Flexible Current Probe (3x), Alligator Clips (4x), colour Coding Set and Documentation on USB Flash Drive Robes, Current Instrument, Energy AnalysePlus software, Line Cords, Magnetic Hanging Strap, Magnetic Voltage Probes (4x), Power Supply, Soft Case, Voltage Test Leads, WiFi/BLE Adapter
Best Voltage Measurement Accuracy:
± (0.2 % + 0.01 %)
Dimensions:
167 x 55 x 198mm
Battery Life:
4 Hours
Current Measurement Resolution:
1 A
