uln2801a STMicroelectronics ULN2801A Octal NPN Darlington Transistor, 500 mA 50 V HFE:1000, 18-Pin DIP

STMicroelectronics ULN2801A Octal NPN Darlington Transistor, 500 mA 50 V HFE:1000, 18-Pin DIP

For more information please check the datasheets.

STMicroelectronics ULN2801A Octal NPN Darlington Transistor, 500 mA 50 V HFE:1000, 18-Pin DIP

Manufacturer:

STMicroelectronics

Manufacturer Part No:

ULN2801A

Enrgtech Part No:

ET12251826

Warranty:

Manufacturer

$ 2.52

Checking for live stock

Transistor Type:

NPN

Maximum Continuous Collector Current:

500 mA

Maximum Collector Emitter Voltage:

50 V

Package Type:

DIP

Mounting Type:

Through Hole

Pin Count:

Transistor Configuration:

Common Emitter

Number of Elements per Chip:

Minimum DC Current Gain:

1000

Maximum Collector Emitter Saturation Voltage:

1.6 V

Minimum Operating Temperature:

-20 °C

Dimensions:

23.24 x 7.1 x 3.676mm

0900766b814b1260.pdf(datasheets)

0900766b81644fae.pdf(datasheets)

Explore Darlington pairs for high-gain switching needs. Enrgtech offers power transistors ideal for amplifiers, controllers, and voltage regulation circuits.
