ECCN:
EAR99
Type:
Time Counter (Hour Meter)
Depth:
38mm
HTSUS:
8531.20.0000
Reset:
Front Panel, Programmable
Series:
-
Weight:
-
Package:
Bulk
Function:
Counter
Approvals:
CE, cUL Recognized, RoHS, UL, WEEE
Count Mode:
Pulse
Count Rate:
40Hz, 500Hz
Input Type:
Voltage
Meter Type:
Electronic
Cutout Size:
45.5 x 22.6 mm
Output Type:
-
RoHS Status:
RoHS non-compliant
Time Format:
-
Cutout Width:
45.5mm
Digit Height:
2 (Annunciators Icon) mm, 8 (Figure) mm
Display Type:
LCD - Black Characters
REACH Status:
Vendor Undefined
Reset Method:
Manual, No Reset, Remote
Cutout Height:
22.6mm
Mounting Type:
Panel Mount
Meter Accuracy:
100%
Operating Mode:
-
Supply Voltage:
3.6 V Battery
Connection Type:
Terminal Block
Count Direction:
Bi-Directional
Number of Digits:
7 (Annunciators Icon), 8 (Figure)
Voltage - Supply:
20 ~ 300VAC, 10 ~ 300VDC
Measurement Range:
0 → 99999999
Termination Style:
Screw Terminal
Ingress Protection:
IP66 - Dust Tight, Water Resistant, NEMA 4, 4X, 12
Output / Interface:
Voltage
Operating Temperature:
-20°C ~ 60°C
Panel Cutout Dimensions:
Rectangular - 45.50mm x 22.60mm
Display Characters - Height:
0.315" (8.00mm)
Number of Characters Per Row:
8
Maximum Operating Temperature:
+60°C
Minimum Operating Temperature:
-20°C
Moisture Sensitivity Level (MSL):
Not Applicable
