Depth:
19mm
Series:
3410
Function:
Hour Meter
Mount Type:
Flush
Cutout Width:
36.8mm
Digit Height:
7mm
Display Type:
LCD
Product Type:
Counter
Reset Method:
No Reset
Cutout Height:
24.1mm
Connection Type:
Spade Terminal
Count Direction:
Bi-Directional
Number of Digits:
8
Standards/Approvals:
CE, cUL Recognized (File # ELIY2.E36690), NEMA 4, NEMA 4x, RoHS Compliant, SAE, UL, WEEE
Maximum Supply Voltage:
300V ac
Maximum Operating Temperature:
60°C
Depth:
19mm
Series:
3410
Function:
Hour Meter
Approvals:
CE, cUL Recognized (File # ELIY2.E36690), NEMA 4, NEMA 4x, RoHS Compliant, SAE, UL, WEEE
Count Mode:
Hours
Input Type:
Voltage
Meter Type:
Electronic
Cutout Size:
36.8 x 24.1 mm
Cutout Width:
36.8mm
Digit Height:
7 mm
Display Type:
LCD
Reset Method:
No Reset
Cutout Height:
24.1mm
Mounting Type:
Flush Mount
Meter Accuracy:
± 0.1 (Room Temperature) %, ± 0.2 (Specified Temperature Range) %
Supply Voltage:
10 → 300 V dc, 20 → 300 V ac
Connection Type:
Spade Terminal
Count Direction:
Bi-Directional
Number of Digits:
8
Measurement Range:
0 → 999999.99 h, 0 → 9999999.9h
Output / Interface:
MOSFET
Minimum Measurement:
0h
Maximum Count Frequency:
50 Hz, 60Hz
Minimum Operating Temperature:
-40°C
