Absolute Maximum AC Current Measurement:
1000A ac
Absolute Maximum AC Voltage Measurement:
1200V ac
Absolute Maximum DC Voltage Measurement:
1700V dc
Absolute Maximum Resistance Measurement:
99.99kΩ
Model Number:
F402
AC Current Measurement Resolution:
10mA
Clamp Meter Type:
AC Current Clamp Meter
Best AC Current Accuracy:
±(1% rdg + 3dgts)
Best AC Voltage Accuracy:
±(1% rdg + 3dgts)
Functions Measured:
AC Current, AC Voltage, Continuity, DC Voltage, Diode, Frequency, In-Rush Current, Resistance, Temperature
True RMS:
Yes
Best DC Voltage Accuracy:
±(1% rdg + 3dgts)
Jaw Capacity Busbars:
48mm
Safety Category Voltage:
CAT III 1500 V, CAT IV 1000V
Battery Type:
LR6
Weight:
600g
Power Source:
Battery
Non-Contact Voltage Detector:
No
Width:
92mm
Length:
272mm
Temperature Measurement Resolution:
0.1°C
Safety Category Level:
CAT III, CAT IV
Battery Life:
>350 h
Maximum Conductor Size:
48mm
AC Voltage Measurement Range:
0.15 to 1200 V AC
AC Voltage Measurement Resolution:
10mV
AC Current Measurement Range:
0.25 to 1000 A AC
Height:
41mm
Minimum Operating Temperature:
-20°C
Maximum Operating Temperature:
+55°C
Best Temperature Measurement Accuracy:
±1% +3°C
Best Resistance Measurement Accuracy:
±1 % + 5 digits
Safety Category:
CAT III 1500 V, CAT IV 1000V
Absolute Maximum Temperature Measurement:
+1000°C
Display Type:
Backlit LCD
DC Voltage Measurement Resolution:
10mV
Dimensions:
92 x 272 x 41mm
Resistance Measurement Resolution:
100mΩ
