Absolute Maximum AC Current Measurement:
600A ac
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum Resistance Measurement:
400Ω
Model Number:
ICM135R
AC Current Measurement Resolution:
100mA
Clamp Meter Type:
AC Current Clamp Meter
Best AC Current Accuracy:
±(1.9% rdg + 5dgts)
Best AC Voltage Accuracy:
±(1% rdg + 5dgts)
True RMS:
Yes
Jaw Capacity Busbars:
34mm
Best DC Voltage Accuracy:
±(0.7% rdg + 2dgts)
Functions Measured:
AC Current, AC Voltage, Continuity, DC Voltage, Diode Test, Frequency, Resistance
Width:
50mm
AC Voltage Measurement Resolution:
100mV
Safety Category Voltage:
600V
DC Voltage Measurement Resolution:
100mV
Dimensions:
76 x 50 x 220mm
Battery Life:
DO-221AD
Maximum Conductor Size:
34 (Dia.)mm
Resistance Measurement Resolution:
100mΩ
Weight:
360g
Safety Category Level:
CAT III
Battery Type:
9V, IEC 6F22, NEDA 1604
Power Source:
Battery
Minimum Operating Temperature:
0°C
Height:
220mm
Length:
76mm
Display Type:
LCD
Maximum Operating Temperature:
+50°C
Safety Category:
CAT III 600 V
Best Resistance Measurement Accuracy:
±1% + 3 Digits
