Absolute Maximum AC Current Measurement:
400A ac
Absolute Maximum DC Current Measurement:
400A dc
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum Resistance Measurement:
40kΩ
Model Number:
325
Calibrated:
RSCAL
AC Current Measurement Resolution:
10mA
DC Current Measurement Resolution:
10mA
Best DC Current Accuracy:
±(2% rdg +5 Digits)
Clamp Meter Type:
AC/DC Clamp Meter
Best AC Current Accuracy:
±(2% rdg +5 Digits)
Best AC Voltage Accuracy:
±(1.5% rdg +5 Digits)
Jaw Capacity Busbars:
30mm
True RMS:
Yes
Best DC Voltage Accuracy:
±(1% rdg +5 Digits)
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Frequency, Resistance, Temperature
Power Source:
Battery
Weight:
283g
Safety Category Level:
CAT III, CAT IV
Height:
34mm
DC Voltage Measurement Resolution:
100mV
Absolute Maximum Temperature Measurement:
+400°C
Maximum Operating Temperature:
+50°C
Resistance Measurement Resolution:
100mΩ
Length:
207mm
Width:
75mm
Safety Category Voltage:
300 V, 600V
Battery Type:
AAA
Display Type:
LCD
Safety Category:
CAT III 600 V, CAT IV 300V
Best Resistance Measurement Accuracy:
1.0% ± 5 Digits
AC Voltage Measurement Resolution:
100mV
AC Current Measurement Range:
40 A, 400 A
Minimum Operating Temperature:
-10°C
AC Voltage Measurement Range:
600 V
Maximum Conductor Size:
30mm
Dimensions:
207 x 75 x 34mm
Temperature Measurement Resolution:
0.1°C
Glove Type:
40 A, 400 A
