Absolute Maximum AC Current Measurement:
600A ac
Absolute Maximum DC Current Measurement:
900A dc
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
59.99kΩ
Model Number:
F205
AC Current Measurement Resolution:
0.01A
DC Current Measurement Resolution:
0.01A
Best DC Current Accuracy:
±(1% rdg + 3digits)
Clamp Meter Type:
AC/DC Clamp Meter
Best AC Current Accuracy:
±(1% rdg + 3digits)
Best AC Voltage Accuracy:
±(1% rdg + 3digits)
True RMS:
Yes
Functions Measured:
AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Diode, Frequency, Harmonics, In-Rush Current, Phase rotation, Power, Power Factor, Resistance
Best DC Voltage Accuracy:
±(1% rdg + 3digits)
Jaw Capacity Busbars:
34mm
Battery Type:
9V 6LR61
Safety Category Voltage:
600V
Maximum Operating Temperature:
+55°C
Display Type:
Backlit LCD
Best Resistance Measurement Accuracy:
±1 % + 5 digits
Safety Category:
CAT III 1000 V, CAT IV 600V
Safety Category Level:
CAT IV
DC Voltage Measurement Resolution:
0.01V
Dimensions:
78 x 42 x 222mm
Length:
78mm
Weight:
354g
Battery Life:
130 h
Width:
42mm
Power Source:
Battery, Mains
Maximum Conductor Size:
34mm
AC Voltage Measurement Resolution:
0.01V
Height:
222mm
Resistance Measurement Resolution:
100mΩ
