Absolute Maximum AC Current Measurement:
1000A ac
Absolute Maximum DC Current Measurement:
1000A dc
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
60kΩ
Model Number:
376
Calibrated:
RSCAL
AC Current Measurement Resolution:
0.1A
DC Current Measurement Resolution:
0.1A
Best DC Current Accuracy:
2 %
Clamp Meter Type:
AC/DC Clamp Meter
Best AC Current Accuracy:
2.5 %
Best AC Voltage Accuracy:
1.5 %
True RMS:
Yes
Best DC Voltage Accuracy:
1 %
Functions Measured:
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Resistance
Jaw Capacity Busbars:
34mm
AC Voltage Measurement Resolution:
0.1V
AC Current Measurement Range:
999.9 A
AC Voltage Measurement Range:
1000 V
Weight:
388g
Safety Category Level:
CAT III, CAT IV
Height:
246mm
Minimum Operating Temperature:
-10°C
Glove Type:
999.9 A
Maximum Operating Temperature:
+50°C
Length:
83mm
Safety Category Voltage:
600 V, 1000V
Battery Type:
AA
Width:
43mm
Safety Category:
CAT III 1000 V, CAT IV 600V
Best Resistance Measurement Accuracy:
1 %
Power Source:
Battery
Dimensions:
83 x 43 x 246mm
Display Type:
Backlight
DC Voltage Measurement Resolution:
0.1V
Resistance Measurement Resolution:
100mΩ
