Chart Type:
Circular
Number of Inputs:
1
Parameter Measured:
Current, Millivolt, Resistance, Temperature, Voltage
Maximum Temperature Measurement:
+1300 °C, +1700 °C, +1800 °C, +300 °C, +600 °C, +900 °C
Maximum Current Measurement:
50mA
Number of Outputs:
1
Maximum Operating Voltage:
240V ac
Input Connector:
750 ￫ 10000Ω
Maximum Voltage Measurement:
+5V
Recorder Input Type:
mA, mV, Thermocouple, V
Model Number p:
C1911
IP Rating:
IP66
Best Temperature Measurement Accuracy:
±0.5 °C, ±1 °C, ±2 °C
Temperature Measurement Resolution:
0.1%
Best Current Measurement Accuracy:
±0.2 %
Best Resistance Measurement Accuracy:
±0.2 %, ±0.5 %
Width:
134mm
Best Voltage Measurement Accuracy:
±0.1 %
Height:
386mm
Weight:
8.2kg
Current Measurement Resolution:
0.1 %
Resistance Measurement Resolution:
0.1%
Voltage Measurement Resolution:
0.1%
Length:
382mm
Power Source:
Mains
Minimum Operating Voltage:
100V ac
